10HP Two Stages Belt Type Air Compressors
7.5kw 10hp 12bar universal piston type air compressor Shanghai
10HP Pump, 270L Tank, 10HP Tri. phase Iron Motor.
Covering: 3m of 4 x 2.5mm2 Electric Cable. Automatic Pressure-Switch. Drain valve. Safety valve. Exhaust Connector. Both of SUMAKE and LACME made in China, Quality assurance Efficient Iron cover tri-phase electric motor. Two stages cast iron air pump (two years guarantee). Industrial level compressors. 10HP tri-phase iron cover motor.
** For more info. about Air Pump & Compresor, welcome to visit our compressor web : www.aircompressors.com.tw
10HP Two Stages Belt Type Air Compressors
10HP Pump, 270L Tank, 10HP Tri. phase Iron Motor.
Compressor Covering:
- 3m of 4 x 2.5mm2 Electric Cable.
- Automatic Pressure-Switch.
- Drain valve.
- Safety valve.
- Exhaust Connector.
- Both of SUMAKE and LACME made in China, Quality assurance
- Efficient Iron cover tri-phase electric motor.
- Two stages cast iron air pump (two years guarantee).
- Industrial level compressors.
- 10HP tri-phase iron cover motor.
|
MODEL # |
LB19-2-20TI-50 (Tri. Phase) |
|
Motor |
10 HP (7.5 KW) |
|
Frequency |
50 HZ/ 380V |
|
Ampere |
|
|
Air inlet |
|
|
Out inlet(90psi/6bar)) |
|
|
Out inlet(115psi/8bar)) |
763 L/Min(26.9 C.F.M) |
|
Free Speed |
Motor-2,900 RPM, Pump-786 RPM |
|
Working pressure |
10 bar |
|
Maxi. Working pressure |
12 bar |
|
Tank Cap. |
270 Liter |
|
N.W. |
249 kgs |
|
LXWXH |
1550x525x |
10HP Two Stages Belt Type Air Compressors
10HP Pump, 270L Tank, 10HP Tri. phase Iron Motor.
Presentation
Lacme Dafeng manufactures Air Pumps, Air Compressors and also excellent source for different accessories. (Jetco Kit, Air Tools, Electric Motor.)
Experience
Lacme Dafeng was founded in 2000 by both LACME (France) company and SUMAKE® (Taiwan) Company, from 50 years experience in manufacturing of air pumps, air compressors and air tools.
Location
Lacme Dafeng is located at Dafeng City (Jiangsu Province) China, in the heart of the most important air compressors area of country. Spare parts suppliers are all around. Two main harbours of China (Shanghai and Nantong) are also very close to us. While our customers are all abroad, this location is a real advantage to give them the best quality products on the best time limit.
Quality and Enhancement
French engineers supervise the production and all spare parts 100% checked.
Additionally, all finished products are strictly controlled before sending. Furthermore, in order to improve our pump's quality and efficiency, our R&D department develops every year many models. Consequently, Lacme Dafeng is best choice to get good quality Air Pumps & Air Compressors from China.
