  • Quality Belt 7.5HP iron motor 3 phase 270L tank pump compressors
  • Quality Belt 7.5HP iron motor 3 phase 270L tank pump compressors

Quality Belt 7.5HP iron motor 3 phase 270L tank pump compressors

Model : LB75-2-75TI-270

7.5HQuality Belt 7.5HP iron motor 3 phase 270L tank pump compressors

Model #

LB75-2-75TI-270

Motor

 7.5 HP (5.5 KW)

Frequency

 50Hz/380V

Ampere

 11.7A

Air inlet

 1078 L/Min (38.1 C.F.M)

Out inlet(90psi/6bar)

 733 L/Min (25.9 C.F.M)

Out inlet(115psi/8bar)

 679 L/Min (24.0 C.F.M)

Free Speed

 Motor-2,898 RPM;

 Pump-1,192 RPM

Working pressure

 8 bar

Maxi. Working pressure

 10 bar

Tank Cap.

 270 Liter

N.W.

 248.5 kgs

LXWXH

 1550x525x1135 mm

Feature:

Accessories incl:

* 3M of 4 x1.5mm2 Power cord

* Drain valve

* Automatic pressure switch

* 1/2" Safety valve

* 1/4" Exhaust connector

* 3/4" Ball Tap.
