Top Quality Hinge Digital Torque Meter

Model : TM-C200

Top Quality Hinge Digital Torque Meter (30~200kgf-cm)

Model # TM-C200



Specification:

Model#

TM-C200

Measuring Range

30~200kgf-cm/3.0~20Nm

Accuracy

± 0.5%

Recharge Time

Within 8 hrs

Power supply

1.2V battery*5

Continuous Operation at full charge

About 30 hours

Battery Life

Rechargeable 300 times

Dimension(WxDxH)

130x180x34 mm

Weight

1.5 kgs

Special Charger

AC 120V, 220-240V

DC 7.2V 120mA




Features-

* LED can identify the test range of torque set by needed user. If the result is not complying to set torque range, light will be warned.

* USB 1.0 connector is only used for data output; it is convenient for user to work with computer.

* Auto-zero can be selected and zero reset becomes unnecessary for user.

* Automatically test values about maximum and mean.
