Industrial Composite Air Impact Wrench-814Nm, 13,500 rpm
♦Twin Hammer Mechanism:
-Powerful torque.
-Precision machined with longer lifespan.
♦Patented One-Hand F/R Switch:
--Easy manual switch over forwarded and reversed.
♦Comfortable Composite Handle:
-Ergonomic and comfortable grips bring less tiring for the operators.
-Rubber Composite Handle could absorb vibrationbetter.
♦Adjustable Torque
-Four phase of the torque setting in forward
-Powerful reversing torque continuously
♦Handle Exhaust With Muffler
ST-C539 /ST-C559 / Industrial Composite Pneumatic Impact Wrench
|
Model No. |
Square Drive (inch) |
Free Speed (r.p.m) |
Max Torque |
Air Inlet (PT) |
Air Hose (ID) |
Air Consumption |
Overall Length |
Net Weight |
Packing Pcs/Ctn/G.W./Cuft (kgs) |
||||
|
ft-lb |
N-m |
cfm |
l/min |
inch |
mm |
lbs |
Kgs |
||||||
|
ST-C539 |
3/8 |
10,000 |
554 |
751 |
1/4” |
3/8” |
15 |
430 |
7.2 |
182 |
2.67 |
1.21 |
8pcs/Ctn/12/1.03' |
|
ST-C559 |
1/2 |
13,500 |
600 |
814 |
1/4” |
3/8” |
17 |
480 |
7.2 |
182 |
2.69 |
1.22 |
8pcs/Ctn/12/1.03' |
